FedEx Package Tracking

Purpose

Given a FedEx tracking number, return the package's current status, last-known location, scheduled or estimated delivery date / time window, service type (Ground / Express / Home Delivery / Ground Economy / Freight / International), signed-by name when delivered, and the full chronological event timeline (timestamp, location, status description). Read-only — never schedules, holds, redirects, or modifies a shipment.

When to Use

• Customer-facing "where is my package?" lookups.
• Logistics monitoring dashboards (e.g., trigger a downstream workflow when status flips to DELIVERED or OUT_FOR_DELIVERY).
• ETA arbitration across multiple carriers (combine with UPS / USPS / DHL skills).
• Anywhere you'd otherwise scrape fedex.com/fedextrack — the official Track API is faster, structurally typed, and not gated by Akamai.

Workflow

FedEx has two viable surfaces. Lead with the official Track API at apis.fedex.com/track/v1/trackingnumbers (OAuth2, free developer tier). The public web flow at fedex.com/fedextrack/?trknbr=... is a fully JS-rendered SPA behind Akamai and pays a 5–15× cost premium per tracking number; use it only when API credentials are unavailable. There is no public unauthenticated JSON endpoint — the internal /trackingCal/track XHR used by the web UI is gated by Akamai session cookies and will 403/404 to cookieless callers (verified: GET returns FedEx Page Not Found; the JS bundle at /wtrk/track/main-*.js exposes the path as constant WTRK_ENDPOINTS.TRKC but it is XHR-only).

Primary path — Track API (recommended)

1. Obtain credentials once. Register at developer.fedex.com, create a Track API project, and capture client_id + client_secret. The same credentials work for both sandbox (apis-sandbox.fedex.com) and production (apis.fedex.com) once the project is approved; sandbox is open immediately, production requires moving the project to Production state on the portal.

2. Mint an access token (cache for ~58 minutes; the token TTL is 60 min):

   POST https://apis.fedex.com/oauth/token
   Content-Type: application/x-www-form-urlencoded

   grant_type=client_credentials&client_id={ID}&client_secret={SECRET}


   Response: {"access_token":"...","token_type":"bearer","expires_in":3600,"scope":"CXS"}. Returns 405 on GET (verified) and 401 with NOT.AUTHORIZED.ERROR on bad creds.

3. Call the tracking endpoint:

   POST https://apis.fedex.com/track/v1/trackingnumbers
   Authorization: Bearer {access_token}
   Content-Type: application/json
   X-locale: en_US

   {
     "includeDetailedScans": true,
     "trackingInfo": [
       { "trackingNumberInfo": { "trackingNumber": "{NUMBER}" } }
     ]
   }


   Up to 30 tracking numbers per call. includeDetailedScans: true is what makes scanEvents[] populated — without it you get only the latest status.

4. Parse the response. Tracking data lives at output.completeTrackResults[i].trackResults[j]. The fields that map to the requested output:

   • Current status — latestStatusDetail.code (DL=delivered, OD=out for delivery, IT=in transit, PU=picked up, OC=order created, SE=shipment exception, CA=canceled) and latestStatusDetail.description for user-facing text. latestStatusDetail.statusByLocale is the localized version.
   • Last-known location — latestStatusDetail.scanLocation (object: city, stateOrProvinceCode, countryCode) or the most recent scanEvents[0].scanLocation. scanEvents[] is sorted newest-first.
   • Scheduled / estimated delivery — estimatedDeliveryTimeWindow.window.{begins,ends} (ISO timestamps; recipients in US/CA/BE/DE/NL on Express/Ground/Home Delivery). Falls back to standardTransitTimeWindow.window.ends or dateAndTimes[].dateTime where dateAndTimes[].type === "ESTIMATED_DELIVERY" or "ACTUAL_DELIVERY".
   • Service type — serviceDetail.type (e.g. GROUND_HOME_DELIVERY, FEDEX_GROUND, FEDEX_EXPRESS_SAVER, PRIORITY_OVERNIGHT, INTERNATIONAL_PRIORITY, FEDEX_FREIGHT_ECONOMY) and serviceDetail.description for the marketing name. SmartPost is now GROUND_ECONOMY post-rebrand.
   • Signed-by name — deliveryDetails.receivedByName when status is DL. Also check deliveryDetails.signatureType (DIRECT, INDIRECT, ADULT, NO_SIGNATURE_REQUIRED); when NO_SIGNATURE_REQUIRED, receivedByName is typically null even though the package is delivered.
   • Event timeline — scanEvents[] array. Each entry: date (ISO), eventType (2-letter code), eventDescription (user-facing), scanLocation.{city,stateOrProvinceCode,countryCode,postalCode}, optional exceptionCode / exceptionDescription, and delayDetail.{status,type,subType} when delayed (status ∈ ON_TIME / EARLY / DELAYED).

5. Surface error states from the response:

   • errors[] at the top level of the request → transport-level error (auth, validation, rate limit).
   • output.alerts[] with alertType: "NOTE" and code like TRACKING.DATA.NOTFOUND.404 → tracking number not found (or too old; FedEx purges most numbers after ~18 months).
   • output.completeTrackResults[].trackResults[].error → per-tracking-number error (invalid format, retired number, etc.).
   • latestStatusDetail.statusByLocale === "Label created" with no scanEvents → label printed but package not yet picked up.

Browser fallback

Use only when API credentials are unavailable. Verified + residential proxy mandatory — fedex.com is Akamai-fronted; bare sessions get Access-Denied HTML. Cost is 5–15× the API path because the entire tracking detail UI renders client-side after the XHR resolves; you cannot read tracking data from the initial HTML (verified: zero hits for the tracking number in the 56KB HTML body returned by direct GET).

SID=$(bb sessions create --keep-alive --verified --proxies | jq -r '.id')

browse --connect "$SID" open "https://www.fedex.com/fedextrack/?trknbr={NUMBER}"
browse --connect "$SID" wait load
browse --connect "$SID" wait timeout 4000      # XHR-driven render is 1–3s after `load`

# Detail view — single tracking number, valid, single shipment:
#   URL contains /apps/wtrk/detailedtracking
#   Snapshot exposes:
#     - heading: "<status>" (e.g. "Delivered", "On the way", "Pending")
#     - subheading: "<service type> · <weight>"
#     - "Scheduled delivery" or "Delivered" date+time row
#     - "Signed for by:" row (when delivered + signature captured)
#     - "Travel history" / "Shipment facts" expanders → click each to enumerate events

browse --connect "$SID" snapshot                 # parse status, dates, signature
browse --connect "$SID" click '@<travel-history-toggle>'   # expand timeline
browse --connect "$SID" snapshot                 # extract scan events

bb sessions update "$SID" --status REQUEST_RELEASE

Branch on the SPA route after navigation (read browse --connect "$SID" get url):

Site-Specific Gotchas

• No public unauthenticated JSON API. apis.fedex.com/track/v1/trackingnumbers requires OAuth2 (returns 401 without Authorization: Bearer ...). The internal /trackingCal/track XHR used by the web UI is bound to Akamai session cookies acquired through a real page load — cookieless POST returns 403/404 (GET → "FedEx Page Not Found", verified). Don't waste cycles trying to call /trackingCal/track from curl.
• Akamai protection on every fedex.com surface. Cookies set on first load: _abck, ak_bmsc, bm_mi, bm_sz, fdx_cbid, fdx_bman, Rbt, xacc, siteDC. A bare-cookie session gets 403 / Access-Denied HTML for browser flows. Always use --verified --proxies.
• The tracking page is a JS SPA, not SSR. GET on /fedextrack/?trknbr=... returns ~56KB of HTML shell + Angular bundle URLs at /wtrk/track/main-*.js — zero tracking data is in the HTML body. Wait at least 3–4 seconds after wait load before snapshotting; the XHR-driven render fires 1–3s after load.
• Use trknbr= not trackingnumber=. Both are accepted but the JS canonicalizes to trknbr; the alt form sometimes triggers a redirect through the landing page that loses session continuity.
• 16-character tracking numbers route to POD-order tracking. The JS guard in chunk-PA2U5XJF redirects tracking_number.length === 16 && action === "track" to appConfig.podOrderTrackingUrl — these are FedEx Delivery Manager confirmation codes, not standard tracking numbers, and require a different flow. Standard FedEx tracking numbers are 12 (Express), 15 (Ground), or 22 digits (SmartPost / Ground Economy).
• Multi-tracking via comma: trknbr=A,B,C lands on /apps/wtrk/multitrkidsummary with one card per shipment — useful for batched lookups, but each card shows summary only (status + ETA); to get full timeline you must click into each.
• trackingQualifier disambiguates duplicates. Some FedEx services (especially Freight and some Express returns) reuse tracking numbers across years. If the API returns multiple results or the browser lands on /duplicate-results, you must pass trkqual= (URL) or trackingNumberInfo.trackingNumberUniqueId (API) to pin to one shipment. The qualifier is opaque; either accept all duplicates and let the caller pick, or pin the most recent by dateAndTimes[type=SHIP].dateTime.
• Private / authenticated shipments: error codes TRACKING.AUTHORIZATION.ERROR and TRACKING.AUTHENTICATEDDELIVERY.ERROR (extracted from the JS bundle) mean the shipper marked the shipment private — the API returns no scan events, only an auth-required note. Recipient ZIP verification is the only unlock and is out of scope for a read-only skill; report as success: false, reason: "authentication_required".
• includeDetailedScans defaults to false. A response with only latestStatusDetail and no scanEvents[] means you forgot the flag — re-request with includeDetailedScans: true.
• scanEvents[] is sorted newest-first. Don't assume chronological; reverse it for a human-readable timeline.
• Estimated Delivery Time Window (EDTW) is regional. Only populated for packages destined to US / CA / BE / DE / NL on Express, Ground, or Home Delivery. International, Freight, and SmartPost / Ground Economy will typically lack estimatedDeliveryTimeWindow; fall back to standardTransitTimeWindow or dateAndTimes[type=ESTIMATED_DELIVERY].
• Service type rebrand: SMART_POST is now GROUND_ECONOMY in the API. Some older records still emit SMART_POST in serviceDetail.type — treat both as the same family. Freight is FEDEX_FREIGHT_PRIORITY / FEDEX_FREIGHT_ECONOMY (no scan events for many freight shipments — the response leans on dateAndTimes only).
• signedByName only for direct-signature services. deliveryDetails.receivedByName is null when signatureType is NO_SIGNATURE_REQUIRED even though the package is delivered — this is not an error; emit signedBy: null and signatureType: "NO_SIGNATURE_REQUIRED" together.
• OAuth token caching. Tokens expire in 3600s. Cache and reuse; don't mint per request — FedEx rate-limits OAuth aggressively (sandbox is more lenient than prod, but neither will tolerate a fresh token per tracking call at scale).
• Rate limits: production Track API caps at ~10 RPS per developer account; bursts above that return 429. Sandbox is much lower. Batch up to 30 numbers per call instead of fanning out.
• Retention: tracking data is typically purged after 18 months. Calls for older numbers return TRACKING.DATA.NOTFOUND.404 even if the package was real and delivered. The web UI renders this as a "Historical Tracking" / "We don't have any information" panel.
• apis-sandbox.fedex.com exists and is open immediately (verified: 405 on GET /oauth/token with the same Layer7 gateway as prod). Use it for development; tracking numbers 123456789012, 111111111111, and 999999999999 are the documented sandbox test numbers covering in-transit / delivered / exception states.

Expected Output

Single shipment, delivered, with signature:

{
  "success": true,
  "trackingNumber": "394002115586",
  "trackingQualifier": "20260514000000",
  "carrier": "FedEx",
  "serviceType": "FEDEX_GROUND",
  "serviceDescription": "FedEx Ground",
  "status": {
    "code": "DL",
    "description": "Delivered",
    "statusByLocale": "Delivered"
  },
  "lastKnownLocation": {
    "city": "MEMPHIS",
    "stateOrProvinceCode": "TN",
    "countryCode": "US"
  },
  "scheduledDelivery": {
    "estimatedWindow": { "begins": "2026-05-15T08:00:00", "ends": "2026-05-15T20:00:00" },
    "actualDelivery": "2026-05-15T14:32:00"
  },
  "signature": {
    "signedBy": "J SMITH",
    "signatureType": "INDIRECT"
  },
  "events": [
    { "timestamp": "2026-05-15T14:32:00", "city": "MEMPHIS", "stateOrProvinceCode": "TN", "countryCode": "US", "eventType": "DL", "description": "Delivered" },
    { "timestamp": "2026-05-15T08:14:00", "city": "MEMPHIS", "stateOrProvinceCode": "TN", "countryCode": "US", "eventType": "OD", "description": "On FedEx vehicle for delivery" },
    { "timestamp": "2026-05-15T05:42:00", "city": "MEMPHIS", "stateOrProvinceCode": "TN", "countryCode": "US", "eventType": "AR", "description": "At local FedEx facility" },
    { "timestamp": "2026-05-14T22:18:00", "city": "OLIVE BRANCH", "stateOrProvinceCode": "MS", "countryCode": "US", "eventType": "DP", "description": "Departed FedEx hub" }
  ]
}

In-transit, no signature yet, EDTW present:

{
  "success": true,
  "trackingNumber": "770000000000",
  "carrier": "FedEx",
  "serviceType": "FEDEX_EXPRESS_SAVER",
  "serviceDescription": "FedEx Express Saver",
  "status": { "code": "IT", "description": "In transit", "statusByLocale": "On the way" },
  "lastKnownLocation": { "city": "INDIANAPOLIS", "stateOrProvinceCode": "IN", "countryCode": "US" },
  "scheduledDelivery": {
    "estimatedWindow": { "begins": "2026-05-19T10:00:00", "ends": "2026-05-19T16:00:00" }
  },
  "signature": null,
  "events": [
    { "timestamp": "2026-05-18T14:02:00", "city": "INDIANAPOLIS", "stateOrProvinceCode": "IN", "countryCode": "US", "eventType": "AR", "description": "Arrived at FedEx hub" },
    { "timestamp": "2026-05-18T03:11:00", "city": "MEMPHIS", "stateOrProvinceCode": "TN", "countryCode": "US", "eventType": "DP", "description": "Departed FedEx hub" }
  ]
}

Delayed (weather), still in transit:

{
  "success": true,
  "trackingNumber": "880000000000",
  "carrier": "FedEx",
  "serviceType": "FEDEX_GROUND",
  "status": { "code": "IT", "description": "In transit", "statusByLocale": "Delay" },
  "delayDetail": { "status": "DELAYED", "type": "WEATHER", "subType": "SNOW" },
  "lastKnownLocation": { "city": "BUFFALO", "stateOrProvinceCode": "NY", "countryCode": "US" },
  "scheduledDelivery": { "estimatedWindow": null },
  "signature": null,
  "events": [
    { "timestamp": "2026-05-18T09:00:00", "city": "BUFFALO", "stateOrProvinceCode": "NY", "countryCode": "US", "eventType": "DE", "description": "Delay – Weather (Snow)" }
  ]
}

Not found / retired:

{
  "success": false,
  "reason": "tracking_number_not_found",
  "trackingNumber": "123456789012",
  "detail": "TRACKING.DATA.NOTFOUND.404 — number unknown to FedEx or older than the 18-month retention window."
}

Private / authentication-required shipment:

{
  "success": false,
  "reason": "authentication_required",
  "trackingNumber": "770000111111",
  "detail": "Shipper marked this shipment private. Recipient ZIP verification required; read-only skill cannot unlock."
}
